PRODUCT DETAILS
GTM’s 50 HP rotary cutter gearbox (Model RGS006) is engineered for high-performance agricultural machinery. Designed for rotary cutters, bush hogs, and PTO-driven implements, this Rotary Cutter Gearbox ensures efficient power transmission, durability, and stable operation in demanding field conditions.
| Parameter | Description |
|---|---|
| Power Rating | 50 HP (37 kW) |
| Gear Ratio | 1:1.33 (customizable ratio options available) |
| Input Speed | 540–1000 RPM (standard PTO compatible) |
| Output Speed | 720–1330 RPM (depending on gear ratio) |
| Mounting Dimensions | Standard flange type, bolt-on installation |
| Input Shaft | 1-3/8” Z6 spline (PTO type) |
| Output Shaft | 1-1/2” round or tapered shaft (optional) |
| Housing Material | High-strength cast iron (optional aluminum or stainless steel) |
| Gear Type | Helical or spur gears, precision ground and heat-treated |
| Lubrication | High-temperature resistant gear oil |
| Service Life | 10,000+ hours under rated load |
This gearbox fits most rotary cutters, mowers, and pasture maintenance implements in the 40–60 HP range.
A reliable gearbox is defined by quiet operation, high strength, and long-lasting performance.
GTM’s RGS006 model offers the following advantages:
Smooth & Quiet Operation: Precision-machined gears ensure minimal vibration and low noise during cutting.
High Load Capacity: Shafts, bearings, and gears are engineered to handle the rated horsepower without deformation.
Leak-Proof Design: Premium oil seals prevent leakage, even under continuous heavy-duty use.
Durable Construction: Reinforced cast iron housing and hardened steel gears resist impact and wear.
Easy Maintenance: Simple lubrication system and modular assembly for convenient servicing.
We provide OEM and fully customized gearbox solutions to meet your exact application needs:
Specification Customization – Gearbox size, capacity, and power rating can be designed according to your machine’s requirements.
Material Customization – Choose from cast iron, aluminum alloy, or stainless steel for housing and internal components, depending on working environment.
Functional Customization – Adjust gear ratio, speed, or rotation direction (forward/reverse) based on actual usage scenarios.
Performance Customization – Modify transmission efficiency, noise level, and service life based on specific technical demands.
Maintenance Service – GTM provides after-sales support, including regular maintenance, troubleshooting, and spare part replacement.
Our R&D engineers can also assist with custom drawings and prototype development for new agricultural machinery models.
GTM has over 25 years of experience exporting agricultural gearboxes worldwide, serving OEMs, distributors, and farm machinery operators in more than 40 countries:
North America: USA & Canada — supporting rotary cutter and PTO implement manufacturers.
Europe: Germany, France, Italy — precision gearboxes for heavy-duty rotary cutters.
Australia & Oceania: Durable units for farm maintenance and land clearing.
Asia & South America: High-performance gearboxes for forestry, agriculture, and landscaping projects.
Our experience ensures reliable delivery, consistent quality, and technical support for global partners.
“GTM’s RGS006 gearbox performs flawlessly on our 50 HP rotary cutters. It handles dense brush without overheating and requires minimal maintenance.”
— Farm Equipment Operator, USA
“We have sourced rotary cutter gearboxes from GTM for over 6 years. Excellent build quality and global shipping support make them our preferred partner.”
— Distributor, Australia
“Our European clients trust GTM gearboxes for long-life performance in heavy-duty grass cutting applications. Highly recommended.”
— OEM Partner, Germany
Rotary cutters / Bush hogs
PTO-driven mowers
Pasture and land maintenance equipment
Agricultural and landscaping implements
25+ years of manufacturing experience in agricultural transmission solutions.
Exported to 40+ countries, serving top-tier agricultural equipment brands.
Certified Quality: ISO9001 & IATF16949 systems for global reliability.
OEM & Custom Design Services for various horsepower and torque requirements.
Proven Field Durability: Long-lasting performance under heavy-duty agricultural workloads.
Looking for a high-quality 50 HP rotary cutter gearbox?
GTM provides OEM and custom gearbox solutions to meet your specific machinery requirements.
Contact our technical team today for drawings, specifications, or a free quotation.
PRODUCT DRAWINGS
ROTARY CUTTER GEARBOX
